Buy Hino Air Filter – SK-1246AB High performance air filter 70024177 for Cummins engine QSF2.8 air filter element AF55312 AF55320 AF55020 – Qiangsheng

Short Description:


Product Detail

Product Tags

Related Video

Feedback (2)

Usually customer-oriented, and it's our ultimate focus on to be not only by far the most reliable, trustable and honest provider, but also the partner for our customers for Semi Truck Air Filters, Air Filter Co, Excavator Air Filter, We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success!
Buy Hino Air Filter – SK-1246AB High performance air filter 70024177 for Cummins engine QSF2.8 air filter element AF55312 AF55320 AF55020 – Qiangsheng Detail:

Problems to be paid attention to in the maintenance of diesel engine air filter

The starting devices of rural tractors and agricultural transport vehicles are equipped with air filters, oil filters and diesel filters, commonly known as “three filters”. The operation of “three filters” directly affects the operation function and service life of the starter. At present, quite a lot of drivers fail to maintain and protect the “three filters” according to the prescribed time and rules, resulting in frequent engine failures and premature entry into the maintenance period. Let’s take a look at it next.

The maintenance master reminds you: the protection and maintenance of the air filter, in addition to the regular and operation and maintenance requirements, should also pay attention to the following points:

1. The guide grille of the air filter should not be deformed or rusted, and its inclination angle should be 30-45 degrees. If the resistance is too small, it will increase and affect airflow. If the airflow is too large, the rotation of the airflow will be weakened and the separation from dust will be reduced. The outer surfaces of the blades do not need to be painted to prevent oxidation particles from entering the cylinder.

2. The ventilation mesh should be cleaned during maintenance. If the filter has a dust cup, the dust particle height should not exceed 1/3, otherwise it should be removed in time; the dust cup mouth should be tightly sealed, and the rubber seal should not be damaged or discard.

3. The height of the oil level of the filter should meet the standard requirements. If the oil level is too high, it will cause carbon deposits in the cylinder. Too low oil reduces the filter’s function and accelerates its wear.

4. When the metal mesh (wire) in the filter is replaced, the diameter of the hole or wire can only be slightly smaller, and the filling capacity cannot be increased. Otherwise, the functionality of the filter will be reduced.

Pay attention to the air leakage of the intake pipe, and the oil change and cleaning should be carried out in a place without wind and dust; the fan filter should be carried out in an environment with low humidity and high pressure air, and the blowing direction should be opposite to the air entering the filter screen; during installation, The folding directions of adjacent filters of Di should penetrate each other.

Product description

SK-1246AB High performance air filter 70024177 for Cummins engine QSF2.8 air filter element AF55312 AF55320 AF55020

A:

QSNO. SK-1246A
OEM NO. CUMMINS 70024177
CROSS REFERENCE AF55320 AF55020
APPLICATION Cummins engine QSF2.8
LENGTH 235/229 (MM)
WIDTH 191/185 (MM)
OVERALL HEIGHT 319/353 (MM)

B:

QSNO. SK-1246B
OEM NO.
CROSS REFERENCE AF55312
APPLICATION Cummins engine QSF2.8
LENGTH 221/(218/224) (MM)
WIDTH 175/(171/177) (MM)
OVERALL HEIGHT 38 (MM)

Our Workshop

workshop
workshop

Packing & Delivery

Packing
Packing

Our Exhibition

workshop

Our service

workshop


Product detail pictures:

Buy Hino Air Filter –  SK-1246AB High performance air filter 70024177 for Cummins engine QSF2.8 air filter element AF55312 AF55320 AF55020 – Qiangsheng detail pictures

Buy Hino Air Filter –  SK-1246AB High performance air filter 70024177 for Cummins engine QSF2.8 air filter element AF55312 AF55320 AF55020 – Qiangsheng detail pictures

Buy Hino Air Filter –  SK-1246AB High performance air filter 70024177 for Cummins engine QSF2.8 air filter element AF55312 AF55320 AF55020 – Qiangsheng detail pictures

Buy Hino Air Filter –  SK-1246AB High performance air filter 70024177 for Cummins engine QSF2.8 air filter element AF55312 AF55320 AF55020 – Qiangsheng detail pictures

Buy Hino Air Filter –  SK-1246AB High performance air filter 70024177 for Cummins engine QSF2.8 air filter element AF55312 AF55320 AF55020 – Qiangsheng detail pictures

Buy Hino Air Filter –  SK-1246AB High performance air filter 70024177 for Cummins engine QSF2.8 air filter element AF55312 AF55320 AF55020 – Qiangsheng detail pictures

Buy Hino Air Filter –  SK-1246AB High performance air filter 70024177 for Cummins engine QSF2.8 air filter element AF55312 AF55320 AF55020 – Qiangsheng detail pictures

Buy Hino Air Filter –  SK-1246AB High performance air filter 70024177 for Cummins engine QSF2.8 air filter element AF55312 AF55320 AF55020 – Qiangsheng detail pictures

Buy Hino Air Filter –  SK-1246AB High performance air filter 70024177 for Cummins engine QSF2.8 air filter element AF55312 AF55320 AF55020 – Qiangsheng detail pictures


Related Product Guide:

Our personnel are generally within the spirit of "continuous improvement and excellence", and using the excellent top quality goods, favorable rate and superior after-sales expert services, we try to win every customer's believe in for Buy Hino Air Filter – SK-1246AB High performance air filter 70024177 for Cummins engine QSF2.8 air filter element AF55312 AF55320 AF55020 – Qiangsheng , The product will supply to all over the world, such as: Czech, Swiss, Australia, With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in this field and other industries. We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success! We welcome customers, business associations and friends from all parts of the world to contact us and seek cooperation for mutual benefits.
  • In China, we have purchased many times, this time is the most successful and most satisfactory, a sincere and realiable Chinese manufacturer!
    5 Stars By ROGER Rivkin from Berlin - 2018.10.01 14:14
    We are really happy to find such a manufacturer that ensuring product quality at the same time the price is very cheap.
    5 Stars By Ann from Slovakia - 2018.12.28 15:18
