OEM High Quality Air Hepa Filter Supplier – SK-1232AB Caterpillar excavator air filter 4969845 4969846 for CATERPILLAR MH3040 352GC 349GC 345GC 336GC 330GC 330 326GC 322 – Qiangsheng
OEM High Quality Air Hepa Filter Supplier – SK-1232AB Caterpillar excavator air filter 4969845 4969846 for CATERPILLAR MH3040 352GC 349GC 345GC 336GC 330GC 330 326GC 322 – Qiangsheng Detail:
Replacement of Caterpillar excavator filter element
Caterpillar excavator filter element matching models are available from stock: Air filter: 131-8822/131-8821; Oil filter element: 322-3155/1R-0739; Diesel filter element: 1R-1804/1R-0751; Oil-water separation filter element: 382- 0664/326-1644;
hydraulic oil return filter element: 179-9806; hydraulic pilot filter element: 093-7521/5I-8670.
Caterpillar Excavator Diesel Filter Replacement Procedure
1. Prepare special tools for easy disassembly
2. Remove the excavator diesel filter counterclockwise
3. Fill the new diesel filter element with diesel oil and replace it
4. Pump oil to exhaust air
Caterpillar Air Filter Replacement Maintenance Interval
The Cat air filter should be replaced or cleaned at least every 2000 hours or when the warning light is on. The outer filter element can be cleaned up to 6 times and then must be replaced. The inner filter element is a one-time item, which cannot
be cleaned and should be replaced directly. If the filter is damaged, it must also be replaced. Use clean, dry compressed air with a maximum pressure of 5 BAR for compressed air. Do not bring the nozzle closer to 3–5 cm. Blow the filter clean from
the inside along the pleats.
Common models of Caterpillar filter elements:
1R-0716, 1R-0762, 1R-0770, 1R-0769, 1R-0751, 1R-0749, 1R-0741, 1R-0739, 1R-0756, 1R-0726, 4N-0015, 4P0711, 4P0710, 142- 1339,142-1404,131-8822,131-8821,6I2505,6I2506,6I2503,6I2504,5I8670,5I7951,6T5068,6T0988,4N8216,4N8220,9L6639,4N6373,5H73714N8221,4W0752,2S5218,8N6700,8N6717,7E4841, 5L7425,4L6060,6N6652,6N6655,2S2743,9L6647,9L6643,9L6648,2W2622,1W1801,7E4609,6N9915,7S8809,9Y9804,4W5374,5I7739,4N5893,5S5918,1152367,
1W3860,7E4609,2W2243,5I7738,1018314,1061111, 1051779.
Caterpillar Filter Features:
1. High-quality filter paper, high filtration efficiency and large ash capacity.
2. The number of folds of the filter element meets the service life requirements.
3. The first and last folds of the filter element are connected by clips or special glue.
4. The material of the central tube is excellent, and it is processed into a spiral shape, which is not easy to deform.
5. High-quality filter glue, so that the filter paper and the end cap are well sealed.
Caterpillar filter element involves: Caterpillar oil filter element, Caterpillar diesel filter element, Caterpillar air filter element, Caterpillar hydraulic oil filter element, Caterpillar oil-water separator filter element and other types of filter elements, ensuring low price, fast supply and excellent quality in the comparison of the same industry in my country.
Product description
SK-1232AB Caterpillar excavator air filter 4969845 4969846 for CATERPILLAR MH3040 352GC 349GC 345GC 336GC 330GC 330 326GC 322
A:
| QSNO. | SK-1232A |
| OEM NO. | 4969845 |
| CROSS REFERENCE | |
| APPLICATION | CATERPILLAR MH 3040352 GC 349 GC 345 GC 336 GC 330 GC 330 326 GC 322 |
| LENGTH | 438/402 (MM) |
| WIDTH | 254/210 (MM) |
| OVERALL HEIGHT | 264/297 (MM) |
B:
| QSNO. | SK-1232B |
| OEM NO. | 4969846 |
| CROSS REFERENCE | |
| APPLICATION | CATERPILLAR MH 3040352 GC 349 GC 345 GC 336 GC 330 GC 330 326 GC 322 |
| LENGTH | 407/402(MM) |
| WIDTH | 222/217 (MM) |
| OVERALL HEIGHT | 39/59/67 (MM) |
