(1) The hydraulic pipeline filter material should have a certain mechanical strength to ensure that it will not be damaged by hydraulic pressure under a certain working pressure.

(2) Under a certain working temperature as usual, the performance is relatively stable and has sufficient durability.

(3) The hydraulic line filter has good corrosion resistance.

(4) The structure is as simple as possible and the size is compact.

(5) Easy to clean and maintain, easy to replace the filter element.

(6) Low cost. The working principle of the hydraulic filter: the working principle of the hydraulic filter: the hydraulic oil enters the pipeline of the filter from the left side, flows from the outer filter element to the inner filter element, and then flows out from the outlet. When the outer filter element is blocked, the pressure rises to reach the opening pressure of the safety valve, and the oil enters the inner filter element through the safety valve, and then flows out from the outlet. The outer filter element has higher precision than the inner filter element, and the inner filter element belongs to the coarse filter element. Yes.

About the maintenance and precautions of the flat vulcanizer

1. In the first week when the machine is put into production, the nut of the column shaft should be tightened frequently.

2. The working oil of hydraulic pipeline filter should not have stolen goods. N32 or N46 hydraulic oil is recommended. The vulcanizer should be used for 3-4 months. Work should be removed, filtered and reused. The oil change period is one year. When renewing hydraulic oil, the inside of the oil tank should be cleaned.

3. When using the vulcanizer, the hydraulic working pressure cannot exceed the specified maximum working pressure to avoid damage to the parts.

Metallurgy: It is used for the filtration of the hydraulic system of rolling mills and continuous casting machines and the filtration of various lubricating equipment. Petrochemical: separation and recovery of products and intermediate products in the process of refining and chemical production, purification of liquids, magnetic tapes, optical discs, and films in the production process, and filtration of oilfield well water and natural gas.
